FLC 30 Cutting Head
Production information
Features
- Able to Cut Steel, Copper, Aluminum and Brass
- Ultra-stable Capacitive Height Sensing
- Vertical and Horizontal Configurations
- Optional Camera with Coaxial Illumination
- 12 kW CW Laser Power Handling
- Broad Range of Focusing Lens and
- CollimatorsCompletely Sealed Design
- Motorized Focus Adjustment Option
- Low Weight Optional Pierce Sensing Capability
Specification
左右滑動看表格| Laser Power | up to 12 kW |
| Collimating Lens, mm | 50, 60, 70, 85, 100 |
| Focusing Lens, mm | 125, 150, 200, 250 |
| Fiber Receiver | HLC8 and LCA |
| Weight (V), kg | ≥ 2.95 |
| Weight (H), kg | ≥ 3.5 |
